8190zlc Chidong Marine Engine Parts for Passenger Ships Push and Standard Component

Model NO. : 8190

Specification : 118

Trademark : jichai

Origin : China

HS Code : 8409999000

Supply Ability : 50000pecises/Year

Certification : ISO9001

Standard Component : Standard Component

Technics : Push

Material : Aluminum

Type : The Piston Pin

Transport Package : Wooden Cases

Customization : Available | Customized Request

Place of Origin : china

MOQ : 1

Price : 10-1000

Packaging Details : Wooden box and carton packaging

Delivery Time : 15 days

Payment Terms : TT,western

Contact Now

8190zlc Chidong Marine Engine Parts for Passenger Ships Push and Standard Component

Series B3000 diesel engines
Series B3000 diesel engines
Model	Rated Power(KW/hp)	Rated Speed(r/min)	Specific fuel consumption(g/kw.h)	Specific oil consumption(g/kw.h)	Overall Dimension LBH(mm)	Net weigh(KG)
B12V190ZL	1320/1500	1200/1500	≤202	≤1.0	295019802206	9300
B12V190PZL	1320/1500	1200/1500	≤202	≤1.0	398022502739	11000
B12V191ZL-1	1140/1200	1040/1200	≤202	≤1.0	295019802206	9300
B12V191PZL-1	1140/1200	1040/1200	≤202	≤1.0	398022502739	11000
B12V191ZL-2	930/1000	840/1000	≤202	≤1.0	295019802206	9300
B12V191PZL-2	930/1000	840/1000	≤202	≤1.0	398022502739	11000
B12V191ZL-3	1180/1300	1080/1300	≤202	≤1.0	295019802206	9300
B12V191PZL-3	1180/1300	1080/1300	≤202	≤1.0	398022502739	11000
BH12V190ZL	1360/1500	1235/1500	≤202	≤1.0	295022802069	9300
BH12V190PZL	1360/1500	1235/1500	≤202	≤1.0	419823452636	11000
BH12V191ZL-1	1160/1200	1060/1200	≤202	≤1.0	295022802069	9300
BH12V191PZL-1	1160/1200	1060/1200	≤202	≤1.0	419823452636	11000
BH12V191ZL-2	960/1000	870/1000	≤202	≤1.0	295022802069	9300
BH12V191PZL-2	960/1000	870/1000	≤202	≤1.0	419823452636	11000
BH12V191ZL-3	1210/1300	1100/1300	≤202	≤1.0	295022802069	9300
BH12V191PZL-3	1210/1300	1100/1300	≤202	≤1.0	419823452636	11000
Main technical data
No. and arrangement of cylinders:12,60.Vee
Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection
Bore:190mm
Stroke:215mm
Total displacement:73.15L
Compression ration:14.5:1
Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel)
Starting method:Air motor or electric motor
Lubricating method:Pressure and splash lubrication

Jinan Guohua Green Power Equipment Co.,Ltd(JNGH),is a high-tech sales &service company of Jinan Diesel Engine Co., Ltd. Established in 2010,JNGH has formed a complete system in sales and after-sales of 190 series engine(jichai brand:6L190,8V190,12V190.16V190) after eight years experience.
Main business scope:
Early stage:Consultation,designation, supply and erection of engine-based power plants,including diesel generator,natural gas generator,coal gas generator and biogas generator.
Mid stage:Parts supply of jinan diesel engine(jichai/chidong brand).JNGH has two warehouses.One located in Jinan which supply the domestic north and south market.One located in Xinjiang province which supply the west market.Thus could delivery parts fast and guarantee the quality.
Later stage:JNGH also offer engine overhaul and maintenance service.With experienced engineer and professional skills,the problems could be easy solved.Not only the domestic China,Ghana,Kazakhstan,Vietnam and Myanmar also could see the trace of JNGH.
8190zlc Chidong Marine Engine Parts for Passenger Ships Push and Standard Component

12VB.05.10.04/05 connecting rod bearing
12VB.01.23A/24A UPPER/LOWER MAIN BEARING METAL
12VB.01.21A/22A LOWER/UPPER THRUST MAIN BEARING
12VB.01.34 CAMSHAFT BEARING
12VB.01.25A THRUST PLATE
12VB.05.09C-GJ piston ring
12V.01.02C cylinder liner
12VB.03.80.05 SEAT,INLET VALVE
12VB.03.37A INLET VALVE
12VB.03.80.05 SEAT,EXHAUST VALVE
12VB.03.22 EXHAUST VALVE
12VB.03.19 SPRING SEAT,LOWER
12VB.03.15 SPRING SEAT,UPPER
Z12V.03.17A VALVE SPRING,INNER
Z12V.03.18A VALVE SPRING,OUTER
12VB.03.80.02 VALVE GUIDE
12VB.03.02 UPPER COCVER,CYLINDER HEAD
12VB.03.11 SEAL RING I
12VB.03.14E LOWER COVER,CYLINDER HEAD
12VB.03.12A SEAL RING II
601.01.25 THRUST PLATE
601.01.23/24 MAIN BEARING METAL
601.05.07/08 CONNECTING ROD BEARING
601.01.34 CAMSHAFT BEARING
B4012C.05.10.04/05 CONNECTING ROD BEARING
